MB-200 5R LCD Touch Panel

200W 5R Beam Moving Head

Parameter Introduction

Voltage and Power Consumption

* Voltage: AC100-240V, 50/60HZ

* Power Consumption: 350W

* Light Source: 5R

* Color Temperature: 8000K average life: 2000hrs

Features

* LENS: High precise glass optical lens

* Motorized Focus, Beam angle (Zoom): 0°~3.8°

* Pan/Tilt: X axis 540°+ fine, Y axis: 250° + fine with speed adjustable

* Move-in-back for pan/tilt

* Interchangeable Colors wheel: 14 color + open, rainbow effect

* Interchangeable Gobo wheel: 17 fixed gobos + Open with frost function

* Gobo shaking, gobo indexing, gobo position

* Prism wheel: 8-facet prism macros and rotation prism in both directions

* Dimming: 0-100% linear adjustment

* Frost: 0-100% linear adjustment

* Wash effect: adjustable wash effects angle

* Focus: linear adjustment

* Mechanical frost, Strobe/shutter, High speed shutter, 0-13Hz random strobe or pulse
strobe

Control Mode

* Control Mode: DMX-512, Master/Slaver, Sound-activated, Auto mode

* 2 DMX-512 Mode: 16/20CH

* Fire retardant plastic housing, Lightweight and easy to hang, Reset over DMX

* Lux: 59,760@ 20meter

Structure Control Mode

* Display: Color LCD Display

* Protection Level: IP20

Dimension & Size

* Net Weight: 19.50 KG

* Gross Weight: 22.00 KG

* Product Size: 52.3cm(L) X 33.7cm(W) X 51.1cm(H)

* Packing Size: 63.5cm(L) X 44.0cm(W) x 72.5cm(H)
