MB-132 2R
132W 2R Beam Moving Head
Parameter Introduction
Voltage and Power Consumption
* Voltage: AC100-240V, 50/60HZ
* Power Consumption: 160W
* Light Source: MSD 2R, OSRAM 132W,
* Color Temperature: 8,300K, average life: 6000hrs
Features
* Motorized Focus, Beam angle (Zoom): 4°
* Pan/Tilt: X axis 540°+ fine, Y axis: 250°+ fine with speed adjustable
* Move-in-back for pan/tilt
* Interchangeable Colors Wheel: 12 color + open, rainbow effect
* Interchangeable Gobo Wheel: 14 fixed gobos + Open with frost function
* Gobo shaking, gobo indexing, gobo position
* Prism wheel: 8-facet prism macros and rotation prism in both directions
* Mechanical dimmer, Mechanical frost, Strobe/shutter, High speed shutter,0-13Hz random
strobe or pulse strobe
Control Mode
* Control Mode: DMX-512, Master/Slaver, Sound-activated, Auto mode
* DMX-512 Mode: 16CH
Structure
* Fire retardant plastic housing, Lightweight and easy to hang, Reset over DMX
* Touch panel menu with LCD Display
* Protection Level: IP20
Dimension & Size
* Net Weight: 11.00 KG
* Product Size: 33cm(L) X 22cm(W) X 42cm(H)
